Monday, 21 May 2018

Deep Sky with the SVBONY T7 W2568A camera, AstroDMx Capture for Linux and a 10 inch, f/4.8 Newtonian

An SVBONY T7 camera was placed at the Newtonian focus of an Orion Europa, 10 inch, f/4.8 Newtonian. Exposures were captured in RAW 8, with real-time dark-frame and flat-field correction using AstroDMx Capture for Linux on a Debian laptop. The exposures were saved as Tiff files. M13 (50 x 15s exposures), M57 (30 x 45s exposures) and M82 (30 x 60s exposures). The exposures were stacked in Deep Sky Stacker running in Wine and Post processed in the Gimp 2.9 and Neat Image.



M82







Screenshot of AstroDMx Capture for Linux capturing M82 data with real-time dark-frame and flat-field correction


M57


M13

Quite acceptable deep-sky images from this low cost SVBONY W2568A high-speed camera. An ideal starter camera.

Sunday, 20 May 2018

High resolution Lunar imaging with an SVBONY T7 W2568A high speed camera, a 10" Newtonian and AstroDMx Capture for Linux

An SVBONY T7 W2568A high speed camera was placed at the Newtonian Focus of an Orion, 10 inch, f/4.8 Newtonian. AstroDMx Capture for Linux running on a Debian Linux laptop, was used to capture 6 overlapping, 1500 frame SER files of the 24.8% waxing, crescent Moon. The best 50% of the frames in each SER file were stacked in Autostakkert! 3 and stitched together into a single image with Microsoft ICE both running in Wine. The resulting image was wavelet processed in Registax 5.1. also running in Wine. The final image was post processed in the Gimp 2.9.

24.8% waxing, crescent Moon


The SVBONY T7 high speed camera can produce High resolution images worthy of more expensive devices.

Saturday, 19 May 2018

ZWO Gamma Gone!

Gamma has been removed from the ZWO SDK!

This means that ZWO cameras will no longer provide a control for gamma.
At first sight this might seem like a strange thing to do, but in reality, it is not.
There is a powerful argument that image processing should be done after the data have been captured.

In general, image processing involves the selective discarding of information in the image data in the effort to recover as much information about the underlying structure of the image, such as the bands on Jupiter, or the arms of a spiral galaxy. If any of the information is discarded at capture time, it is lost forever, whilst if it is discarded post capture, it is still available in the original image data.

Gamma is such a function that involves the selective changing of the mid-range values of the brightness of an image, whilst leaving the darkest and the lightest values untouched. Many cameras allow the control of gamma at capture time, as it can produce a more pleasing view of the subject being captured. However, it must never be forgotten that the brightness values that are changed (and thus lost) will not be available in the captured data.

Experienced planetary imagers such as Christopher Go, eschew the control of gamma at capture time. What is important is to get the exposure, including gain, right at capture time. Some advanced imaging cameras only allow the control of exposure and these are often true 16 bit devices.

In order to mitigate this loss of control over gamma, Nicola has incorporated gamma control in software, in AstroDMx Capture for Linux. In addition to gamma, she has also implemented contrast and brightness in software. This allows the user to control and see a pleasing view of the subject being imaged as usual. However, the changes are not propagated through to the saved image. This means that no information is discarded at capture time and is therefore available for extraction during post processing in software such as the Gimp 2.10.

For many users, this is a paradigm shift that will require a little getting used to. However, it is likely to lead to better results in the long run.

These changes are implemented in the next release of AstroDMx Capture and have been responsible for the slight delay in release.

Monday, 14 May 2018

First Light testing of the SVBONY version of the T7 high speed astrocamera as a Linux astro-imager with AstroDMx Capture for Linux


This is a low priced astronomy camera that is a suitable introduction to astronomical imaging; not only of the Solar system but also some of the deep sky objects.
The camera is marketed as a high-speed camera and, by implication, a planetary camera.
It can be obtained from the SVBONY official AliExpress store.
I have tested the camera specifically as a Linux astronomical camera using AstroDMx Capture for Linux. The camera supplied by SVBONY was packaged well and includes a number of items.

The box contains
    • The T7 W2568A astrocamera
    • A wide angle lens
    • An auto-guiding cable
    • A USB 2.0 cable
    • An IR/UV cut filter assembly
    • An extension nose-piece
    • Two dust caps
    • A par-focal ring with three thumbscrews. place

The camera with the par-focal ring in place


The par-focal ring is of a superior design with the three thumb screws engaging on an internal O-ring so the screws don’t actually make contact with the camera (or eyepiece) body.

One of the first things to do with a camera of this design is to place a patch of insulating tape over the auto-guiding port. This will ensure that the camera USB cable is not accidentally plugged into the guiding port in the dark. Some manufacturers provide a blanking plug for this purpose but many do not.

The auto-guiding port protected by insulating tape


The substantial par-focal ring can be seen clearly with its three retaining screws.

There are very handy calibration marks on the side of the camera body, making re-positioning much easier.

Calibration marks on the camera body



The camera reports itself as a ZWOASI120MC although it contains a MT9M034 sensor rather than the AR013OCS of the ZWO. The camera will stream 8 bit images and it will stream 16 bit (12 bit in a 16 bit container) images for short exposures. The camera will not reliably deliver 16 bit long exposures. This is not a serious limitation for a camera of low cost. (Moreover, a similar issue is evident in the USB 2.0 ZWO with 16 bit long exposures if the compatibility firmware is used.) In this experiment, the standard camera firmware was used, and a Linux machine with the kernel patched to eliminate the maxpacket limitation in the USB data stream was employed. Note! with the Linux Kernel 4.16.8-300.fc28.x86_64 released by a Fedora 28 update on May 15, 2018, no kernel patch is needed. 16 bit short exposures could be advantageous with solar imaging where the capture of subtly different levels of brightness is important. With 8 bit images, 256 distinct levels of brightness can be recorded, whereas, with 12 bit output (into a 16 bit container) 4096 distinct levels of brightness can be recorded.

Deep Sky imaging

The SVBONY T7 astrocamera was placed at the Newtonian focus of an f/5, Skywatcher Explorer 130 P-DS Newtonian mounted on a Celestron AVX, EQ, GOTO mount. 30 x 20s exposures of M3 were made with real-time dark-frame correction, saving the images as TIFF files using RAW 8 capture with high quality de-bayering on the fly.

Screenshot of AstroDMx Capture for Linux streaming images of M3 without real-time dark-frame correction


Note the background noise in the displayed image.

Screenshot of AstroDMx Capture for Linux streaming images of M3 with real-time dark-frame correction


Note the removal of the background noise by the real-time dark-frame correction.

Animation alternating between the real-time dark-frame corrected and uncorrected views


The real-time dark-frame correction is ideal for outreach and ‘eyepiece sharing’ observing and imaging.
The images were stacked in Deep Sky Stacker running in Wine and post processed in The Gimp 2.10

M3




40 x 35s exposures of M104 were made with real-time dark-frame correction using AstroDMx Capture for Linux, saving the images as TIFF files using RAW 8 capture with high quality de-bayering on the fly.
The images were stacked in Deep Sky Stacker running in Wine and post processed in The Gimp 2.10 and Neat Image.

M104



Planetary imaging

The camera was then tested in its high speed planetary camera mode. The lens from a x2 Barlow was screwed onto the nose-piece of the camera which was then placed at the Cassegrain focus of a Skymax 127 Maksutov. A region of interest of 320 x 240 was selected and a 2min SER file of Jupiter was collected (under poor seeing conditions) using RAW 8 capture with high quality de-bayering on the fly. 10,000 frames were captured. The best 40% of frames were stacked in Autostakkert! 3 and wavelet processed in Registax 5.1 both running in Wine. The final image was post processed in the Gimp 2.10

Jupiter with the GRS



First impressions of the SVBONY T7 camera are that is is a very good value device, ideal  as an introductory camera for Solar System and brighter deep sky object astrophotography. It is an impressive device and has capabilities that will produce pleasing results. Depending on the exposure, with a region of interest of 230 x 240, a frame rate of up to 250fps can be achieved. It should also be noticed that relatively small aperture telescopes have been used for the current tests. Later testing will involve the use of much larger aperture telescopes.

Monday, 7 May 2018

Deep sky with a QHY 5-ll-M and AstroDMx Capture for Linux

A Bresser Messier-AR-102-AS ED refractor was mounted on a Celestron AVX, EQ, GOTO mount. A QHY 5-ll-M camera was placed at the prime focus. AstroDMx Capture for Linux was used to capture 16 bit FITs files with matching dark frames.
M104 ans M64 were captured with 20 x 50s exposures M3 was captured with 40 x 16s exposures.
The Fits files were stacked with dark-frame correction in Deep Sky Stacker, running in Wine. The resulting images were processed in FITs Liberator and post processed in The Gimp 2.9.
With M3, the stacked image was processed by four transformations in FITs Liberator (arcsin, root, log(root) and log(log)). The images were converted to BMPs and combined with weighting in Andrew Sprott's Flexible Image Combine (FIC).

M3

M64

M104


FULL SIZE
M3

M64

M104

Jupiter with an SVBONY SV105 camera, a Skymax 127 and AstroDMx Capture for Linux

An SVBONY SV105 camera was placed at the Cassegrain focus of a Skymax 127 Maksutov. AstroDMx Capture for Linux was used to capture a 3 min SER file of Jupiter. The best 25% of the 2292 frames captured were stacked in Autostakkert!3 and wavelet processed in Registax 5.1, both running in Wine. The final image was post processed in The Gimp 2.10. Ganymede and the Great Red Spot are both visible.


Considering the fact that the seeing was poor and the telescope only has a 5" aperture, the detail in the image is acceptable from this low cost camera.

Tuesday, 1 May 2018

Bug in the recent Linux kernels affecting Video 4 Linux

There is a bug that has been introduced into the Linux kernel since April 12, 2018.
The bug manifests itself as each V4L camera on the USB bus being presented twice. This is the information I have at the moments on the versions involved:
This problem has been found on Fedora kernels but may be present in other kernels.

Fedora Linux kernel version

4.15.17    Apl 12    works correctly
4.16.4      Apr 24    kernel bug displaying 2 devices
4.16.5      Apr 27    kernel bug displaying 2 devices

In AstroDMx Capture for Linux, the bug shows itself at connect time:

Screenshot of the camera connect dialogue showing the cameras presenting twice

Everything will work fine if the first instance of the device is chosen.
It should be noted that this is a bug in the Linux kernel, not in AstroDMx Capture for Linux.
The bug has been reported to the kernel developers and we shall have to see how long they take to fix it. At the moment one can solve the problem by booting into an earlier version of the kernel, or by simply choosing the first device when two are presented. Cameras that are not V4L cameras are not affected.
Nicola has implemented a workaround to eliminate this problem. It will be present in the next release of AstroDMx Capture for Linux.

Sunday, 29 April 2018

The terminator of the 98.5% waxing, gibbous Moon with AstroDMx Capture, a SVBONY SV105 camera and a Bresser Messier-AR-102XS ED refractor

An SVBONY SV105 camera was fitted with a Baader green continuum filter and a x2 Barlow using the refractor at f/9. AstroDMx Capture for Linux was used to capture 4 overlapping, unsaturated, 1500 frame SER files with real-time flat-field correction of the terminator of the 98.5% waxing Moon. The best 75% of the frames in each of the SER files were stacked in Autostakkert! 3, wavelet processed in Registax 5.1 and stitched into a mosaic by Microsoft ICE, all running in Wine. The final image was post processed in the Gimp 2.9.



Using the Barlow still allowed significant oversampling with the 3 micron pixels of the SV105. The 10nm bandpass continuum filter in the middle of the visible, provided light reduction for the very sensitive camera, and eliminates any possible dispersion, notwithstanding the ED objective of the telescope

Friday, 27 April 2018

Modifying a Celestron Omni XLT 150 Newtonian for using a light pollution (or other) filter when a DSLR is directly connected to the telescope.

The Omni XLT 150 f/5 Newtonian, shares a problem with a number of other Newtonians in that when a DSLR camera is connected to the focuser via a 1.25" adapter, the scope does not have enough back focus to allow the image to be brought to focus.
The solutions to this problem have been:

  • Use a Barlow lens to increase the focal length of the system. This allows focus to be achieved, but at the expense of brightness of the image and field of view.
  • Move the position of the mirror further up the tube. This is a drastic solution, and is particularly difficult with the Omni XLT 150.
  • To use the direct camera connect threads on the focuser that allow a camera T-ring to be screwed to the end of the focuser tube. This has the advantage of allowing the camera to be brought to focus. Another, important consequence of using the direct connection method is that the camera cannot fall out of the focuser as could happen with a 1.25" adapter, if the tightening screws have become loose. Moreover, with direct attachment, there is less potential for vignetting. However, there is a huge disadvantage to the direct attachment method: it is not possible to use a light pollution filter, which makes a critical difference if the sky suffers from even slight light pollution. Moreover, if the user wishes to use any other filter, the same problem arises.
  • There are also, some astronomy cameras that do not have a filter-threaded nose piece. With some scopes this is not a problem because a threaded extender tube can be used. However, with many Newtonians this is not possible because the camera is now held too far out to achieve focus.


We show here, an experimental method of allowing a 1.25" light pollution filter to be used with direct camera connection. This is a solution that could be adopted by Celestron (or any other manufacturer) at very little cost, as a standard component of the focuser.

First, a Barlow lens was disassembled so that the middle tube, which is filter threaded, could be removed and used as an internal filter holder in the focuser tube.


A thin shim of plastic tape was placed around the middle tube and it was inserted tightly into the focuser tube and fixed in place with superglue.


The filter threaded Barlow tube was pushed far enough into the tube to allow the 1.25" adapter to be screwed back into place for normal eyepiece work. This adapter has to be removed for filter insertion and direct camera attachment.


After removal of the 1.25" adapter, the Light Pollution filter can be screwed into the Barlow tube threads.


The T-ring can then be attached as usual, ready for direct camera attachment.

Or the 1.25" adapter can be replaced, with the filter in place, for use with a camera that does not have a filter thread as in a camera tested recently.


It is unlikely that this procedure will introduce any more vignetting into the image than would have been produced if the scope had enough back focus to allow a 1.25" adapter to have been used.

In my view, any scope with the facility to attach a DSLR directly to the focuser, should have a filter threaded section inside the focuser to allow the use of filters, in particular, light pollution filters.

Tuesday, 24 April 2018

FITs files, AstroDMx Capture for Linux and a Bresser Messier AR-102XS ED, f/4.5 refractor,

Nicola has implemented FITs files in AstroDMx Capture for Linux. These are the first tests of this implementation.

A Bresser Messier AR-102XS ED, f/4.5 refractor, was mounted on a Celestron AVX, EQ, GOTO mount. A  QHY5L-ll-M camera was mounted at the prime focus and AstroDMx Capture for Linux, running on a Fedora laptop was used to capture Fits files with matching dark-frames. The FITs files were stacked in Deep Sky Stacker 4.1 running in Wine 3.5 and post processed in the Gimp 2.9.

Click on an image to get a closer view.

M65 and M66 in Leo, M51 in Ursa Major and M3 in Bootes were the objects imaged. 16 bit FITs images were captured throughout (12 bit images in a 16 bit FITs container).

20 x 30s exposures were captured of M65 and M66.


30 x 45s exposures were captured of M51


50 x 5s exposures were captured of M3.

A new release will be made when Nicola has added more functionality to the filter-wheel controls.
